Anker und Montagewinkel
Eindreh- und Einschlaganker von DEFLEX® kommen in der Blendrahmenprofilierung zum Einsatz. In unserem Produktportfolio finden Sie eine große Auswahl passend zu Schüco AWS, Schüco Royal S, Heroal, Rehau und anderen.
DEFLEX® Montagewinkel für bodentiefe Fenster- und Türelemente werden mittels Montageschrauben im Beton verankert. Durch die Profilierung wird eine höhere Kraftableitung erzielt.
Connection angle 45+50 mm opening outside
For fixing base profiles and frame extensions with frame and sill.
DEFLEX ID:
7608604550
Article is available
Connection angle 45+ 100 mm opening inside
For fixing base profiles and frame extensions with frame and sill.
DEFLEX ID:
7608614510
Article is available
Connection angle 45+ 100 mm opening outside
For fixing base profiles and frame extensions with frame and sill.
DEFLEX ID:
7608604510
Article is available
Connection angle 45+ 50 mm opening inside
For fixing base profiles and frame extensions with frame and sill.
DEFLEX ID:
7608614550
Article is available
Connection angle 45/30 mm opening inside
For fixing base profiles and frame extensions with frame and sill.
DEFLEX ID:
7608614530
Article is available
Connection angle 45/30 mm opening outside
For fixing base profiles and frame extensions with frame and sill.
DEFLEX ID:
7608604530
Article is available
mounting bracket 150100 FV 150 x 100 x 2 mm
for floor-to-ceiling window and door elements. The attachment in concrete is done by means of mounting screws. Two different hole diameters for fixing. Easy adjustment through slots. Due to the profiling, a higher power dissipation is achieved.
DEFLEX ID:
7608415010
Article is available
mounting bracket 200100 FV 200 x 100 x 2 mm
for floor-to-ceiling window and door elements. The attachment in concrete is done by means of mounting screws. Two different hole diameters for fixing. Easy adjustment through slots. Due to the profiling, a higher power dissipation is achieved.
DEFLEX ID:
7608420010
Article is available
mounting bracket 220100 FV 220 x 100 x 2 mm
for floor-to-ceiling window and door elements. The attachment in concrete is done by means of mounting screws. Two different hole diameters for fixing. Easy adjustment through slots. Due to the profiling, a higher power dissipation is achieved.
DEFLEX ID:
7608422010
Article on request
mounting bracket 240100 FV 240 x 100 x 2 mm
for floor-to-ceiling window and door elements. The attachment in concrete is done by means of mounting screws. Two different hole diameters for fixing. Easy adjustment through slots. Due to the profiling, a higher power dissipation is achieved.
DEFLEX ID:
7608424010
Article is available
mounting bracket 260100 FV 260 x 100 x 2 mm
for floor-to-ceiling window and door elements. The attachment in concrete is done by means of mounting screws. Two different hole diameters for fixing. Easy adjustment through slots. Due to the profiling, a higher power dissipation is achieved.
DEFLEX ID:
7608426010
Article on request
mounting bracket 280100 FV 280 x 100 x 2 mm
for floor-to-ceiling window and door elements. The attachment in concrete is done by means of mounting screws. Two different hole diameters for fixing. Easy adjustment through slots. Due to the profiling, a higher power dissipation is achieved.
DEFLEX ID:
7608428010
Article is available
mounting bracket 300100 FV 300 x 100 x 2 mm
for floor-to-ceiling window and door elements. The attachment in concrete is done by means of mounting screws. Two different hole diameters for fixing. Easy adjustment through slots. Due to the profiling, a higher power dissipation is achieved.
DEFLEX ID:
7608430010
Article is available
punch-in anchor 51-33
Fits with REHAU S729 / S730, TROCAL INNINOVA 70, TROCAL, for use in the frame profile. Rotatable, with external toothing. Lashing dimensions 150/25 / 1,25 mm, claw measurement 40,1 / 8,8 mm
DEFLEX ID:
7602951330
Article is available
punch-in anchor 51-35
fits with ALUPLAST IDEAL 2000-8000, Schüco Corona, for use in frame profiling. Rotatable, with external toothing. Lashing dimensions 150 x 25 x 1.25 mm, claw size 35.8 / 10.0 mm
DEFLEX ID:
7602951350
Article is available
punch-in anchor 51-58
fits with VEKA TOPLINE / SOFTLINE 70mm / 82mm, for use in the frame profile. Rotatable, with external toothing. Lashing dimensions 150 x 25 x 1.25 mm, claw measurement 41.9 / 9.0 mm
DEFLEX ID:
7602951580
Article on request
punch-in anchor 51-64
alternative to system number 228797, fits with Schüco Corona CT70, SI82, for use in the glare frame profile. Rotatable, with external teeth. bracket size 150 x 25 x 1.25 mm, claw size 37.0 / 10.0 mm
DEFLEX ID:
7602951640
Article on request
punch-in anchor 55-05
Fits with TROCAL INNONOVA70, TROCKAL88 +, REHAU GENEO, EURO86, for use in the frame profiling. Rotatable, with external toothing. Lashing dimensions 200 x 25 x 1.25 mm, claw measurement 40.1 / 8.8 mm
DEFLEX ID:
7602955050
Article is available
punch-in anchor 55-11
Fits with VEKA 70mm, VEKA ALPHALINE 90, for use in the frame profile. Rotatable, with external toothing. Lashing dimensions 200 x 25 x 1.25 mm, claw measurement 41.9 / 9.0 mm
DEFLEX ID:
7602955110
Article on request
punch-in anchor 55-20
fits with Schüco Corona CT70, SI82, for use in window frame profiling. Rotatable, with external toothing. Lashing dimensions 200 x 25 x 1.25 mm, claw dimensions 37.0 / 10.0 mm
DEFLEX ID:
7602955200
Article is available
punch-in anchor 55-21
Fits with GEALAN S7000 / S8000 / S9000, for use in window frame profiling. Rotatable, with external toothing. Lashing dimensions 200 x 25 x 1.25 mm, claw measurement 43.2 / 7.8 mm
DEFLEX ID:
7602955210
Article is available
punch-in anchor 55-45
Fits KÖMMERLING 76 and 88, for use in the frame profile. Rotatable, with external toothing. Lashing dimensions 200 x 25 x 1.25 mm, claw measurement 46.3 / 9.3 mm
DEFLEX ID:
7602955450
Article is available
punch-in anchor 55-63
Fits with GEALAN S7000, S8000, S9000, for use in window frame profiling. Rotatable, with external toothing. Lashing dimensions 150/25 / 1,25 mm, claw measurement 43,2 / 7,8 mm
DEFLEX ID:
7602951630
Article is available
